Eutech 560G Ceiling Filter Roll - 2100mm x 20Mtr

Eutech 560G Ceiling Filter Roll - 2100mm x 20Mtr

Regular price $900.00 AUD
Regular price Sale price $900.00 AUD
Sale Sold out
Quantity

Eutech 560G ceiling filter is manufactured to a high standard. Ceiling filter is the first stage of filtration

to eliminate dust and other contaminants from entering your spray booth. The filter media is manufactured

with a progressive density to optimise filter life and provide excellent filtration. A tackifying agent is applied

throughout the manufacturing process to ensure each fibre is coated to enhance the dust holding capability.

Our ceiling filter has been tested and exceeds the worldwide filtration standard EN779.

Tests performed returned a 97.9% arrestance of airborne contaminates, which is equivalent to leading European ceiling filter brands.

These filters are suitable for use in all full down draft and semi downdraft spray booths.


Technical Data Sheet
Initial pressure loss  27Pa
Final pressure loss  400Pa
Average arrestance  97.9%
Dust holding capacity  435g/m²
Thickness  25mm
Media area  1.0m²
Rated air flow  900m³/hr
Max temperature allowed (peaks)  120°C
Air velocity at test  0.25m/sec

Efficiency class according to DIN 24185  F5
Fire resistance (DIN 53438)  F1
